# Flock-You: Promiscuous WiFi Edition (`promiscious-dev` branch) Flock You **Passive 2.4 GHz promiscuous-mode detector for Flock Safety surveillance infrastructure. Runs standalone or feeds the Flask dashboard over USB for live GPS-tagged wardriving.** > **Dev note:** This is the `promiscious-dev` branch — adds the > DeFlockJoplin wildcard-probe tightening and a 31st OUI on top of the > `promiscious` baseline. See "Further research" below. --- ## Credit All WiFi promiscuous detection research — the **30-OUI target list**, the **promiscuous-mode strategy**, and the **addr1-receiver detection technique** — is the work of **ØяĐöØцяöЪöяцฐ / @NitekryDPaul**. The firmware here is a mod of his original firmware with added SPIFFS persistence and Flask-dashboard integration. Full research writeup: [`datasets/NitekryDPaul_wifi_ouis.md`](datasets/NitekryDPaul_wifi_ouis.md). Additional research credit to **Michael / DeFlockJoplin** for the **wildcard-probe-request signature** and the 31st OUI (`82:6b:f2`). Field-tested to 11/12 cameras caught with only 2 false positives in Joplin. Source: [DeflockJoplin/flock-you](https://github.com/DeflockJoplin/flock-you). --- ## What this branch does Turns a Seeed XIAO ESP32-S3 into a passive WiFi receiver that watches 2.4 GHz management and data frames for Flock Safety MAC OUIs. No AP, no transmit — the radio stays dedicated to sniffing while the device hops channels 1 / 6 / 11 at 350 ms dwell. Every detection is: - beeped (piezo on GPIO3) and flashed (onboard LED on GPIO21) - written to on-device SPIFFS in an atomic CRC-envelope format, surviving power loss - emitted as one JSON line over USB CDC in the schema `api/flockyou.py` expects, so the Flask dashboard auto-ingests it with GPS temporal matching The device works standalone (no USB host needed) and plugged in (live dashboard) without any mode switch. --- ## Why promiscuous mode, and why `addr1` Most WiFi sniffers only check the transmitter address (`addr2`). Flock infrastructure spends most of its duty cycle **asleep** — it wakes briefly in bursts, uploads, then sleeps again. During the silence it may never transmit a single frame in your capture window. But it may still appear on the air as the **destination** (`addr1`) of probe responses or data frames from nearby APs. Checking `addr1` in addition to `addr2` picks those silent stations up. It requires two guards to avoid false positives: - `addr1` is broadcast (`ff:ff:ff:ff:ff:ff`) in beacons and broadcasts — **multicast filter** - Modern devices use randomised (locally-administered) MACs that can't be fingerprinted by OUI — **randomised-MAC filter** on byte 0 bit 1 Both are applied before the OUI match. This whole approach, including the 30-OUI list, is **@NitekryDPaul's research**. --- ## Further research — the wildcard-probe signature (DeFlockJoplin) Michael / DeFlockJoplin used the OUI + addr1/addr2/addr3 work above as a starting point and characterised what Flock cameras actually do on the air. His finding: > The cameras are hopping channels and sending out a wildcard WiFi probe request on every channel. This specific type of request combined with OUI matching has created what seems to be a fairly unique signature. His drive-test in Joplin caught **11 of 12 cameras** with only **2 false positives**. The 12th camera was doing the same wildcard-probe behaviour but with an OUI (`82:6b:f2`) that wasn't in @NitekryDPaul's original 30 — it's now the 31st entry in our list, credited to him. The tightened signature that's active on this branch: 1. Frame is 802.11 Management, type=0 subtype=4 (**Probe Request**) 2. SSID Information Element (tag 0) is present with **length 0** (wildcard) 3. `addr2` (transmitter) matches the known-OUI list When all three hit, we emit `detection_method: wifi_wildcard_probe` — the high-precision class. Non-probe frames from the same OUIs still emit `wifi_oui_addr2`, and the `addr1` receiver-side sleeper-catch still runs independently. His proof-of-concept firmware (different enough we're not just pulling it in wholesale, but the core idea carried over cleanly): [DeflockJoplin/flock-you](https://github.com/DeflockJoplin/flock-you). The wildcard-probe analysis is his; we ported the detection into this firmware and kept our SPIFFS persistence, Flask JSON emission, and audio/LED feedback on top. --- ## Detection pipeline ``` [2.4GHz air] │ ▼ wifiSniffer() ← IRAM promiscuous callback (WiFi task) │ fast match only, no Serial / no malloc ▼ alertQueue[32] ← lock-free ring buffer (ISR-safe mux) │ ▼ drainAlertQueue() ← loop() context, per-iteration drain │ ├─► fyAddDetection() ← always, every hit │ │ │ ▼ │ fyDet[200] ← unique-by-MAC on-device table │ │ │ ▼ │ autosaveTick() ← every 60s when dirty │ │ │ ▼ │ fySaveSession() ← atomic CRC-envelope write to SPIFFS │ ├─► shouldSuppressDuplicate() ← 5s per-MAC serial-emit rate limit │ └─► emitDetectionJSON() ← USB CDC line for Flask buzzerBeep() + ledFlash() ``` The split between callback and loop is deliberate: the WiFi task has hard real-time constraints and cannot call `Serial.print` or `malloc` safely. The callback writes only to the lock-free ring buffer; `loop()` does all the heavy work. --- ## OUI target list (@NitekryDPaul research) All lowercase, colon-separated. 31 Flock Safety infrastructure prefixes: ``` 70:c9:4e 3c:91:80 d8:f3:bc 80:30:49 b8:35:32 14:5a:fc 74:4c:a1 08:3a:88 9c:2f:9d c0:35:32 94:08:53 e4:aa:ea f4:6a:dd f8:a2:d6 24:b2:b9 00:f4:8d d0:39:57 e8:d0:fc e0:4f:43 b8:1e:a4 70:08:94 58:8e:81 ec:1b:bd 3c:71:bf 58:00:e3 90:35:ea 5c:93:a2 64:6e:69 48:27:ea a4:cf:12 82:6b:f2 ← contributed by Michael / DeFlockJoplin ``` Pre-compiled into a byte table in `setup()` so the matcher stays entirely in IRAM with no flash-resident lookups during callback execution. Full dataset and methodology: [`datasets/NitekryDPaul_wifi_ouis.md`](datasets/NitekryDPaul_wifi_ouis.md). --- ## SPIFFS wire format On-flash layout, atomic and crash-safe: ``` Line 1: {"v":1,"count":N,"bytes":B,"crc":"0xXXXXXXXX"} Line 2: [{"mac":"...","method":"...","rssi":...,...},...] ``` Save procedure: 1. Compute CRC32 + byte count over the serialised payload 2. Write envelope header + payload to `/session.tmp` 3. Re-read and re-validate `/session.tmp` (CRC check) 4. Remove `/session.json` 5. Atomic rename `/session.tmp` → `/session.json` (copy+delete fallback) Boot recovery: 1. If `/session.json` validates, promote it to `/prev_session.json` 2. Otherwise try `/session.tmp` (interrupted save) 3. Delete both working files, start with an empty live table 4. `/prev_session.json` stays around for inspection CRC32 uses the standard `0xEDB88320` polynomial so the same file can be verified on a host with any off-the-shelf CRC tool. --- ## Flask dashboard integration The firmware emits one JSON line per detection in the same schema the BLE detector uses, so `api/flockyou.py` picks it up with zero changes: ```json {"event":"detection","detection_method":"wifi_oui_addr2","protocol":"wifi_2_4ghz","mac_address":"aa:bb:cc:dd:ee:ff","oui":"aa:bb:cc","device_name":"","rssi":-62,"channel":6,"frequency":2437,"ssid":""} ``` `detection_method` values: - `wifi_wildcard_probe` — **Probe Request + wildcard SSID from a known OUI** (the DeFlockJoplin high-precision signature). When this fires, the `addr2` broad alert is suppressed for the same frame to avoid double-counting. - `wifi_oui_addr2` — transmitter-side OUI match on any non-probe frame - `wifi_oui_addr1` — **receiver-side OUI match** (the @NitekryDPaul technique) - `wifi_oui_addr3` — BSSID OUI match (mgmt frames only; disabled by default) - `wifi_ssid` — SSID keyword match (disabled by default) ### GPS wardriving GPS is handled Flask-side, since the ESP32 radio is dedicated to sniffing and there's no on-device AP. Two options: - **USB NMEA puck** plugged into the host running Flask — Flask reads NMEA and timestamps a GPS timeline - **Flask dashboard open in a phone browser** — browser Geolocation API posts updates to Flask Flask does a temporal match between detection timestamp and GPS timeline, then exports JSON / CSV / KML for Google Earth. ### Running Flask ```bash cd api pip install -r requirements.txt python flockyou.py ``` Open `http://localhost:5000`, pick your serial port from the UI, detections start showing up live. --- ## Hardware **Board:** Seeed Studio XIAO ESP32-S3 | Pin | Function | |-----|----------| | GPIO 3 | Piezo buzzer | | GPIO 21 | Onboard user LED (active low) | | GPIO 43 | Serial1 TX mirror (115200 baud) | Boot sound: first 6 notes of Super Mario Bros. World 1-2 (underground). --- ## Build and flash Requires [PlatformIO](https://platformio.org/). ```bash pio run # build pio run -t upload # flash pio device monitor # serial output ``` `platformio.ini` and `partitions.csv` are at the root (1.9 MB SPIFFS partition, 6 MB app). No extra libraries needed beyond the Arduino-ESP32 core that ships with the espressif32 platform. --- ## Config cheatsheet (top of `main.cpp`) | Define | Default | Notes | |---|---|---| | `CHANNEL_MODE` | `CHANNEL_MODE_CUSTOM` | `CUSTOM` (1/6/11), `FULL_HOP` (1-11), or `SINGLE` | | `CHANNEL_DWELL_MS` | 350 | Time on each channel before hop | | `RSSI_MIN` | -95 | Drop frames weaker than this | | `ALERT_COOLDOWN_MS` | 5000 | Per-MAC serial-emit rate limit | | `CHECK_ADDR1` | 1 | The @NitekryDPaul receiver-side technique | | `CHECK_ADDR3` | 0 | BSSID fallback (mgmt frames only) | | `ENABLE_SSID_MATCH` | 0 | Substring match against `target_ssid_keywords[]` | | `PROCESS_MGMT_FRAMES` | 1 | Beacons, probe req/resp, etc. | | `PROCESS_DATA_FRAMES` | 1 | Data frames (where addr1 catch shines) | | `MAX_DETECTIONS` | 200 | On-device table cap | | `AUTOSAVE_INTERVAL_MS` | 60000 | SPIFFS save cadence | | `LED_PIN` | 21 | Onboard user LED | | `BUZZER_PIN` | 3 | Piezo | --- ## Standalone vs connected **Without USB:** device boots, plays the SMB 1-2 intro, starts scanning, stores every unique detection to SPIFFS, flashes the onboard LED on each hit. Plug in later — the prior session is sitting in `/prev_session.json`. **With USB + Flask running:** same thing, plus every detection streams live to the dashboard as a JSON line. Flask adds GPS (if configured) and deduplicates across MAC, building the wardriving map as you move. Both modes work simultaneously — the SPIFFS write path doesn't care if a host is listening. --- ## BLE companion firmware The BLE-only sibling of this firmware lives on the [`main` branch](https://github.com/colonelpanichacks/flock-you/tree/main). It detects Flock and Raven gear via BLE advertisements (OUI prefix, device name, manufacturer ID `0x09C8`, Raven service UUIDs), runs its own WiFi AP with a phone-facing dashboard at `192.168.4.1`, and emits the same Flask JSON schema. Flash both on separate boards for overlapping BLE + WiFi coverage feeding one Flask dashboard. --- ## Acknowledgments - **ØяĐöØцяöЪöяцฐ (@NitekryDPaul)** — **WiFi promiscuous detection research**: the 30-OUI Flock Safety target list and the addr1-receiver detection technique that are the baseline of this firmware. The code here is a mod of his original work. - **Michael / DeFlockJoplin** ([DeflockJoplin/flock-you](https://github.com/DeflockJoplin/flock-you), [deflockjoplin.today](https://deflockjoplin.today)) — **wildcard-probe-request signature** + the 31st OUI (`82:6b:f2`). Drive-tested in Joplin to 11/12 cameras caught with only 2 false positives. - **Will Greenberg** ([@wgreenberg](https://github.com/wgreenberg)) — BLE manufacturer company ID detection (`0x09C8` XUNTONG) sourced from his [flock-you](https://github.com/wgreenberg/flock-you) fork (used by the BLE companion on `main`) - **[DeFlock](https://deflock.me)** ([FoggedLens/deflock](https://github.com/FoggedLens/deflock)) — crowdsourced ALPR location data and detection methodologies. Datasets included in `datasets/` - **[GainSec](https://github.com/GainSec)** — Raven BLE service UUID dataset (`raven_configurations.json`) used by the BLE companion --- ## OUI-SPY Firmware Ecosystem Flock-You is part of the OUI-SPY firmware family: | Firmware | Description | Board | |----------|-------------|-------| | **[OUI-SPY Unified](https://github.com/colonelpanichacks/oui-spy-unified-blue)** | Multi-mode BLE + WiFi detector | ESP32-S3 / ESP32-C5 | | **[OUI-SPY Detector](https://github.com/colonelpanichacks/ouispy-detector)** | Targeted BLE scanner with OUI filtering | ESP32-S3 | | **[OUI-SPY Foxhunter](https://github.com/colonelpanichacks/ouispy-foxhunter)** | RSSI-based proximity tracker | ESP32-S3 | | **[Flock You](https://github.com/colonelpanichacks/flock-you)** | Flock Safety / Raven surveillance detection (this project) | ESP32-S3 | | **[Sky-Spy](https://github.com/colonelpanichacks/Sky-Spy)** | Drone Remote ID detection | ESP32-S3 / ESP32-C5 | | **[Remote-ID-Spoofer](https://github.com/colonelpanichacks/Remote-ID-Spoofer)** | WiFi Remote ID spoofer & simulator with swarm mode | ESP32-S3 | | **[OUI-SPY UniPwn](https://github.com/colonelpanichacks/Oui-Spy-UniPwn)** | Unitree robot exploitation system | ESP32-S3 | --- ## Author **colonelpanichacks** **Oui-Spy devices available at [colonelpanic.tech](https://colonelpanic.tech)** --- ## Disclaimer Passive reception of publicly-broadcast 802.11 frames for security research, privacy auditing, and education. The device does not transmit and does not authenticate to any network. Detecting the presence of surveillance hardware in public spaces is legal in most jurisdictions; always comply with local laws regarding wireless reception.
